ATSC/8VSB test demodulator broadband, constellation diagram, output MPEG2 data stream
Rohde and Schwarz EFAv53 Overview
Rohde and Schwarz EFAv53 All Available Options
| B11 |
6 MHz SAW filter for digital EFA models or EFA-B10, EFA-B20 (retrofittable by service) |
| B12 |
7 MHz SAW filter for digital EFA models or EFA-B10, EFA-B20 retrofittable by service |
| B13 |
8 MHz SAW filter for EFA 5X/6X/7X or EFA-B20 + EFA-K21/22/23, retrofittable by service |
| B14 |
2 MHz SAW filter for EFA5X/6X/7X or EFA-B20 + EFA-K21/22/23 retrofittable by service |
| B3 |
Selection for demodulator (versions 33/43/53/63/73/89/93) (retrofittable by service) |
| B30 |
M/N demodulator for fitting into digital units, retrofittable by service |
| B4 |
MPEG2 decoder (retrofittable by service) |
| B6 |
Video distributor 4 video outputs (only versions 33/53/89/93) |
| C3 |
Three years of depot calibration coverage based on the R&S recommended calibration interval - includes test data. |
| C5 |
Five years of calibration coverage based on the R&S recommended calibration interval - includes test data. |
| DCV |
Documentation of EFA calibration values |
| K1 |
EFA scan for EFA versions 20,23,40,43, 60,63,70,73 |
| K21 |
DVB-C/J.83/A/C (QAM) FW for versions 5X/7X or B20 (included in version 6X) |
| K23 |
J.83/B (QAM) FW for versions 5X/6X or B20 (included in version 7X) |
| K25 |
Firmware for FIR coefficients readout only for EFA5X or EFA-B20 + EFA-K22 |
| R3 |
Three years of depot repair coverage, including re-calibration if necessary to complete the repair. |
| R5 |
Five years of depot repair coverage, including re-calibration if necessary to complete the repair. |
