Tektronix SD-48 Overview
The Tektronix SD48 is an Optical-to-Electrical Converter.
-
Performance Characteristics
- Form Factor Module (proprietary interface/bus)
- Type Converters
- Minimum Wavelength 950 nm
- Maximum Wavelength 1650 nm
- The SD48 are optical-to-electrical (O/E) converters for use with the Tektronix CSA803 and 11800 Series sampling oscilloscopes equipped with an SD2x or SD3x Electrical Sampling Head. The SD48 Optical-to-Electrical Converters can be plugged directly into an 11800 sampling slot or CSA803 power slot.
- Optical signal input on the SSD48 is a standard FC/PC fiber optic connector. Other connector types can be accommodated by using optional hybrid fiber optic jumper cables (SD42) or an assortment of hybrid mating adapters which are standard with the SD48.
- Out of Production May-27-2001
- CE Compliance Compliant
- UL Compliance Not applicable
- Input Power Not required
